May 2024

Conference Paper

Design of Auxiliary Power Supply for Medium Voltage Applications

By:
Magri Kimpara, Marcio Luiz ; Kandula, Rajendra Prasad ; Harter, Jonathan J; Boone, Christian L
Page Number:
1-7
Issue Number:
NA
Book Title:
2023 IEEE Design Methodologies Conference (DMC)
Publication Date:
May 8, 2024
Publisher Location:
IEEE, New Jersey, United States of America
Conference Name:
IEEE Design Methodologies Conference (DMC)
Conference Location:
Miami, Florida, United States of America
Conference Sponsor:
DOE - TRAC
View DOI Listing:
https://doi.org/10.1109/DMC58182.2023.10412494

Abstract

Typical voltage levels from medium-voltage (MV) applications introduce additional challenges to designing the auxiliary power supply (APS) necessary to provide power to the secondary circuits of the main converter. This paper aims to present the design of a 100 W APS for 0.6–2 kV input DC voltage and 24 V output. The selected architecture addresses the medium voltage to low voltage challenge by adopting two stage approach – a simple robust DC transformer (DCX) stage and a low voltage regulation stage. The design of the main building blocks of the APS are described followed by simulation results.
