Implementation of a Spacer Grid Rod Thermal-Hydraulic Reconstruction (ROTHCON) Capability into the Thermal-Hydraulic Subchannel Code CTF

Abstract

The Consortium for Advanced Simulation of Light Water Reactors is developing a core simulator capability known as the Virtual Environment for Reactor Applications (VERA) to address nuclear industry challenge problems such as crud-induced power shift (CIPS). The CTF thermal-hydraulic (T/H) subchannel code provides thermal feedback in the coupled neutronics, T/H, crud chemistry simulation that VERA performs. It has been discovered that the coarse meshing approach used by CTF (in which fuel rods are discretized into four azimuthal segments) can be a source of error in predicting crud growth and boron distribution in VERA CIPS calculations. Spacer grid effects lead to complex rod-to-fluid heat transfer behavior that, when not resolved, can lead to error in the prediction of crud growth and boron deposition. A higher-fidelity computational fluid dynamics approach can be used instead of CTF, but this leads to excessive simulation times. This paper presents an approach for using high-fidelity computational fluid dynamics data to create shape functions that are used in CTF to reconstruct rod surface heat transfer behavior as a function of spacer grid geometry. The approach is demonstrated for a 5 × 5 rod bundle facility with five mixing vane grids under a range of operating conditions encountered in nominal pressurized water reactor conditions. It is demonstrated that the grid heat transfer maps are successful at introducing a higher-fidelity heat transfer modeling capability into CTF.
