December 2023

Conference Paper

Three-Phase LCC-LCC Compensated 50-kW Wireless Charging System with Non-Zero Interphase Coupling

By:
Mohammad, Mostak ; Pries, Jason L; Onar, Omer C; Galigekere, Veda Prakash ; Su, Gui-Jia ; Wilkins, Jonathan P
Page Number:
456-462
Book Title:
2021 IEEE Applied Power Electronics Conference and Exposition (APEC)
Publication Date:
December 27, 2023
Publisher Location:
IEEE, United States of America
Conference Name:
Applied Power Electronics Conference (APEC)
Conference Location:
Phoenix, Arizona, United States of America
Conference Sponsor:
IEEE
View DOI Listing:
https://doi.org/10.1109/APEC42165.2021.9487224

Abstract

In this paper, an LCC-LCC compensated 50 kW 3phase (3φ) wireless charging system with nonzero interphase mutual inductance is demonstrated. The 3φ-LCC compensation is designed considering a nonzero mutual-inductance among the phase-coils to meet resonance criteria, balance voltages and currents of the resonant tank components, achieve desired voltage gain, and ensure the zero-voltage switching (ZVS) operation. An experimental prototype of the 3φ-LCC-LCC compensation circuit is built for a 50 kW bipolar coil-based 3φ wireless charging system. The prototype system was tested at rated 50 kW power for evaluating the efficiency, ZVS operation, electric and magnetic field emissions, and thermal characteristics. The experimental results show 94.3% dc-to-dc efficiency and only 4.4 μT rms magnetic field emission at the rated 50 kW output power.
